Compound Balance Weave Belt
products description
Compound Balance Weave Belt | High-Temp Stable & Anti-Warp Design
Compound Balance Belt: ±0.2mm stability at 1100°C for glass tempering/metal sintering. 304/316L/314 SS with 3x lower thermal expansion vs standard.
Jiangsu Huada’s compound balance weave belts combine dual-layer precision weaving and reinforced cross rods to deliver unmatched stability for extreme industrial environments. Engineered with 314/316L stainless steel, our belts provide:
2X Load Capacity (up to 600 kg/m² vs. single-layer belts)
±0.1mm/m Linear Accuracy for precision automation
800°C Continuous Operation with zero warping
Certifications:
√ ISO 9001:2015 | √ CE Machinery Directive | √ FDA 21 CFR 177.2600
Technical Advantage
√ Multi-Layer Stability
Dual-layer interlock design with 2.5-5.0mm wire diameter
Tensile strength: 900-1,500 N/mm² (customizable)
√ High-Temperature Resilience
Material: 314 SS (800°C) / Inconel 600 (1,100°C)
Thermal expansion coefficient: 12.5×10⁻⁶/°C
√ Precision Engineering
Cross-rod alignment tolerance: ±0.15mm
Optional ESD-safe coating (10⁶-10⁹Ω surface resistance)
Application Scenarios
| Industry | Application | Huada Advantage |
| Automotive | Stamping press transfer lines | 5.0mm wires withstand 15-ton presses |
| Mining | Ore sorting conveyors | Tungsten-carbide rod reinforcement |
| Food Processing | High-speed baking lines | 316L SS with EHEDG certification |
| Glass Manufacturing | Tempered glass annealing | Zero deflection at 650°C |
Technical Parameters
| Parameter | Huada Compound Weave Belt | Industry Standard |
| Max Load Capacity | 600 kg/m² | 300 kg/m² |
| Temperature Range | -50°C to 800°C | -30°C to 600°C |
| Abrasion Resistance | 0.5 cm³ (ASTM G65) | 2.0 cm³ |
| Hygienic Cleanability | EHEDG Type EL Class I | Basic CIP compliance |
Case Study: Tier-1 Automotive Supplier
Huada’s compound belts solved our stamping line alignment issues:
Zero part misalignment in 500,000 cycles
25% faster line speeds with 4.5mm wire design
Reduced 40% maintenance costs over 2 years
